מק"ט: PC/ABS 32

מסמכים

Order symbol	Product nbr	EAN	Dimensions (mm)	Description • Remarks
CAB PCQ 302017 G	8113338	6418074011145	300 x 200 x 170	Cabinet, PC • Grey cover
CAB PCQ 302017 T	8113038	6418074011077	300 x 200 x 170	Cabinet, PC • Smoked transparent cover
CAB ABSQ 302017 G	8183338	6418074011282	300 x 200 x 170	Cabinet, ABS • Grey cover
CAB ABSQ 302017 T	8183038	6418074011213	300 x 200 x 170	Cabinet, ABS • Smoked transparent cover
Accessories
EKIV 23	4712117	6418074032713	170 x 270	Mounting plate, for enclosures:
EKIV 17	4712126	6418074032768	35 x 166	DIN-35 Mounting rail, for enclosures:
EKIV 27	4712127	6418074032775	35 x 266	DIN-35 Mounting rail, for enclosures:
FP A 23	8392226	6418074021564	166 x 268	Swing-out door/Front plate (aluminium), for enclosures:
MB 12225 AL	8390007	6418074033116		Swing door set • for aluminium front plates
FP 12-23	8392218	6418074021618	178 x 278	Front plate, for enclosures: • 12 modules
DRF 23	4712200	6418074040923		DIN rail frame set, for enclosures:
DRF 33	4712205	6418074040930		DIN rail frame set, for enclosures:
PAT 12040	4512040	6418074032409		Hinge set • incl. screws
