מק"ט: PC/ABS 5628

מסמכים

Order symbol	Product nbr	EAN	Dimensions (mm)	Description • Remarks
PC 5628 13 G	5330364	6418074005601	558 x 278 x 130	Enclosure, PC • Grey cover
PC 5628 13 G-3FSH	2539525	6418074052759	558 x 278 x 130	Enclosure, PC • Grey hinged cover
PC 5628 13 T	5330064	6418074005595	558 x 278 x 130	Enclosure, PC • Transparent cover
PC 5628 13 T-3FSH	2539555	6418074052872	558 x 278 x 130	Enclosure, PC • Transparent hinged cover
ABS 5628 13 G	5880364	6418074039101	558 x 278 x 130	Enclosure, ABS • Grey cover
ABS 5628 13 G-3FSH	9880441	6418074053473	558 x 278 x 130	Enclosure, ABS • Grey hinged cover
ABS 5628 13 T	5880064	6418074039224	558 x 278 x 130	Enclosure, ABS • Transparent cover
ABS 5628 13 T-3FSH	9996271	6418074060990	558 x 278 x 130	Enclosure, ABS • Transparent hinged cover
Accessories
EKTVT	3770553	6418074039798	518 x 238	Mounting plate, for enclosures:
EKV 22	3770648	6418074031976	35 x 235	DIN-35 Mounting rail, for enclosures:
EKV 50	3770699	6418074030405	35 x 500	DIN-35 Mounting rail, for enclosures:
EKTZR	3730142	6418074005762	558 x 278 x 50	Extension frame, for enclosures:
