מפה הנדסת חשמל בע"מ

מק"ט: PC/ABS 5638

מסמכים

Order symbol	Product nbr	EAN	Dimensions (mm)	Description • Remarks
PC 5638 18 G	5330365	6418074005625	558 x 378 x 180	Enclosure, PC • Grey cover
PC 5638 18 G-3FSH	2539527	6418074052810	558 x 378 x 180	Enclosure, PC • Grey hinged cover
PC 5638 18 T	5330065	6418074005618	558 x 378 x 180	Enclosure, PC • Transparent cover
PC 5638 18 T-3FSH	2539557	6418074052933	558 x 378 x 180	Enclosure, PC • Transparent hinged cover
ABS 5638 18 G	5880365	6418074039118	558 x 378 x 180	Enclosure, ABS • Grey cover
ABS 5638 18 G-3FSH	9880445	6418074053534	558 x 378 x 180	Enclosure, ABS • Grey hinged cover
ABS 5638 18 T	5880065	6418074039231	558 x 378 x 180	Enclosure, ABS • Transparent cover
ABS 5638 18 T-3FSH	9996272	6418074061058	558 x 378 x 180	Enclosure, ABS • Transparent hinged cover
Accessories
EKUVT	3770554	6418074039804	518 x 338	Mounting plate, for enclosures:
EKV 32	3770649	6418074031983	35 x 335	DIN-35 Mounting rail, for enclosures:
EKUZR	3730323	6418074005779	558 x 378 x 50	Extension frame, for enclosures:
