מק"ט: PC/ABS 17/16

מסמכים

Order symbol	Product nbr	EAN	Dimensions (mm)	Description • Remarks
PC 17/16-C3	7520080	6418074010179	166 x 160 x 108	Enclosure, PC • Without main cover
PC 17/16-3	7525165	6418074056726	188 x 160 x 134	Enclosure, PC • Smoked transparent hinged cover
PC 17/16-3TT	7526165	6418074062024	188 x 160 x 134	Enclosure, PC • Clear transparent hinged cover
PC 17/16-FC3	7520280	6418074010254	166 x 160 x 118	Enclosure, PC • Grey screw cover
ABS 17/16-C3	7580080	6418074010193	166 x 160 x 108	Enclosure, ABS • Without main cover
ABS 17/16-3	7585165	6418074056771	188 x 160 x 134	Enclosure, ABS • Smoked transparent hinged cover
ABS 17/16-3TT	7586165	6418074062086	188 x 160 x 134	Enclosure, ABS • Clear transparent hinged cover
Accessories
MP 17/16	7720071	6418074036735	136 x 133	Mounting plate, for enclosures:
FP 17/16	7720070	6418074035783	158 x 98	Front plate (aluminium), for enclosures:
FC PC 17/16	7720102	6418074034687	166 x 106 x 16	Frame of PC front plate, for enclosures:
