מפה הנדסת חשמל בע"מ

מק"ט: PC/ABS 25/22

מסמכים

Order symbol	Product nbr	EAN	Dimensions (mm)	Description • Remarks
PC 25/22-C3	7520141	6418074059352	257 x 219 x 122	Enclosure, PC • Without main cover
PC 25/22-3	7525134	6418074059390	280 x 219 x 156	Enclosure, PC • Smoked transparent hinged cover
PC 25/22-3TT	7526134	6418074062048	280 x 219 x 156	Enclosure, PC • Clear transparent hinged cover
PC 25/22-FC3	7520241	6418074059376	257 x 219 x 135	Enclosure, PC • Grey screw cover
ABS 25/22-C3	7580141	6418074059369	257 x 219 x 122	Enclosure, ABS • Without main cover
ABS 25/22-3	7585134	6418074059406	280 x 219 x 156	Enclosure, ABS • Smoked transparent hinged cover
ABS 25/22-3TT	7586134	6418074062109	280 x 219 x 156	Enclosure, ABS • Clear transparent hinged cover
Accessories
MP 25/22	7720140	6418074059307	225 x 175	Mounting plate, for enclosures:
FP 25/22	7720139	6418074059291	250 x 150	Front plate (aluminium), for enclosures:
FC PC 25/22	7720111	6418074059338	257 x 157 x 30	Frame of PC front plate, for enclosures:
