מפה הנדסת חשמל בע"מ

מק"ט: PC/ABS 0816

מסמכים

Order symbol	Product nbr	EAN	Dimensions (mm)	Description • Remarks
PC 081606	7032630	6418074058379	160 x 80 x 55	Enclosure, PC • Grey cover
PC 081607	7032620	6418074003638	160 x 80 x 65	Enclosure, PC • Grey cover
PC 081609	7032650	6418074058386	160 x 80 x 85	Enclosure, PC • Grey cover
PC 081610	7032640	6418074003645	160 x 80 x 95	Enclosure, PC • Grey cover
PCT 081606	7022631	6418074058584	160 x 80 x 55	Enclosure, PC • Transparent cover
PCT 081607	7022621	6418074003751	160 x 80 x 65	Enclosure, PC • Transparent cover
PCT 081609	7022651	6418074058591	160 x 80 x 85	Enclosure, PC • Transparent cover
PCT 081610	7022641	6418074003768	160 x 80 x 95	Enclosure, PC • Transparent cover
AB 081606	7083630	6418074058799	160 x 80 x 55	Enclosure, ABS • Grey cover
AB 081607	7083620	6418074003515	160 x 80 x 65	Enclosure, ABS • Grey cover
AB 081609	7083650	6418074058805	160 x 80 x 85	Enclosure, ABS • Grey cover
AB 081610	7083640	6418074003522	160 x 80 x 95	Enclosure, ABS • Grey cover
Accessories
TM 0816	9512013	6418074034014	71 x 134	Mounting plate, for enclosures:
TRM 0808	9820004	6418074034144	15 x 68	DIN-15 Mounting rail, for enclosures:
TRM 0816	9820013	6418074034168	15 x 146	DIN-15 Mounting rail, for enclosures:
TRH 1216	9822028	6418074034410	35 x 146	DIN-35 Mounting rail, for enclosures:
TF 28037	7028337	6418074033734		Wall fastening lug (4 pcs), for enclosures: • incl. screws
TH A	9802001	6418074034120		Grey plastic hinges (2 pcs) • incl. mounting screws
