מפה הנדסת חשמל בע"מ

מק"ט: PC/ABS 1212

מסמכים

Order symbol	Product nbr	EAN	Dimensions (mm)	Description • Remarks
PC 121207	7032660	6418074005199	122 x 120 x 65	Enclosure, PC • Grey cover
PC 121208	7032670	6418074058393	122 x 120 x 75	Enclosure, PC • Grey cover
PC 121210	7032680	6418074003652	122 x 120 x 95	Enclosure, PC • Grey cover
PC 121211	7032690	6418074058409	122 x 120 x 105	Enclosure, PC • Grey cover
PCT 121207	7022661	6418074005205	122 x 120 x 65	Enclosure, PC • Transparent cover
PCT 121208	7022671	6418074058607	122 x 120 x 75	Enclosure, PC • Transparent cover
PCT 121210	7022681	6418074003775	122 x 120 x 95	Enclosure, PC • Transparent cover
PCT 121211	7022691	6418074058614	122 x 120 x 105	Enclosure, PC • Transparent cover
AB 121207	7083660	6418074036872	122 x 120 x 65	Enclosure, ABS • Grey cover
AB 121208	7083670	6418074058812	122 x 120 x 75	Enclosure, ABS • Grey cover
AB 121210	7083680	6418074003539	122 x 120 x 95	Enclosure, ABS • Grey cover
AB 121211	7083690	6418074058829	122 x 120 x 105	Enclosure, ABS • Grey cover
Accessories
TM 1212	9512014	6418074034021	96 x 111	Mounting plate, for enclosures:
TRM 0812	9820009	6418074034151	15 x 106	DIN-15 Mounting rail, for enclosures:
TRM 1212	9820008	6418074034175	15 x 110	DIN-15 Mounting rail, for enclosures:
TRH 1212	9822002	6418074034403	35 x 110	DIN-35 Mounting rail, for enclosures:
TF 28037	7028337	6418074033734		Wall fastening lug (4 pcs), for enclosures: • incl. screws
TH A	9802001	6418074034120		Grey plastic hinges (2 pcs) • incl. mounting screws
