מפה הנדסת חשמל בע"מ

מק"ט: PC/ABS 1625

מסמכים

Order symbol	Product nbr	EAN	Dimensions (mm)	Description • Remarks
PC 162509	7032840	6418074003683	250 x 160 x 90	Enclosure, PC • Grey cover
PC 162513	7032860	6418074003690	250 x 160 x 125	Enclosure, PC • Grey cover
PC 162515	7032740	6418074058485	250 x 160 x 150	Enclosure, PC • Grey cover
PCT 162509	7022841	6418074003805	250 x 160 x 90	Enclosure, PC • Transparent cover
PCT 162513	7022861	6418074003812	250 x 160 x 125	Enclosure, PC • Transparent cover
PCT 162515	7022741	6418074058690	250 x 160 x 150	Enclosure, PC • Transparent cover
AB 162509	7083840	6418074003560	250 x 160 x 90	Enclosure, ABS • Grey cover
AB 162513	7083860	6418074003577	250 x 160 x 125	Enclosure, ABS • Grey cover
AB 162515	7083740	6418074058904	250 x 160 x 150	Enclosure, ABS • Grey cover
Accessories
TM 1625	9512018	6418074034076	151 x 224	Mounting plate, for enclosures:
TRM 0816	9820013	6418074034168	15 x 146	DIN-15 Mounting rail, for enclosures:
TRH 1216	9822028	6418074034410	35 x 146	DIN-35 Mounting rail, for enclosures:
TRH 24	9822008	6418074034397	35 x 226	DIN-35 Mounting rail, for enclosures:
TF 28037	7028337	6418074033734		Wall fastening lug (4 pcs), for enclosures: • incl. screws
TH A	9802001	6418074034120		Grey plastic hinges (2 pcs) • incl. mounting screws
