מק"ט: PC/ABS 1220

מסמכים

Order symbol	Product nbr	EAN	Dimensions (mm)	Description • Remarks
PC 122008	7032760	6418074003676	200 x 120 x 75	Enclosure, PC • Grey cover
PC 122009	7032770	6418074058423	200 x 120 x 90	Enclosure, PC • Grey cover
PCT 122008	7022761	6418074003799	200 x 120 x 75	Enclosure, PC • Transparent cover
PCT 122009	7022771	6418074058638	200 x 120 x 90	Enclosure, PC • Transparent cover
AB 122008	7083760	6418074003553	200 x 120 x 75	Enclosure, ABS • Grey cover
AB 122009	7083770	6418074058843	200 x 120 x 90	Enclosure, ABS • Grey cover
Accessories
TM 1220	9512015	6418074034045	111 x 174	Mounting plate, for enclosures:
MIV 10	5514082	6418074033192	35 x 100	DIN-35 Mounting rail, for enclosures:
TRH 1220	9822006	6418074034427	35 x 186	DIN-35 Mounting rail, for enclosures:
TF 28037	7028337	6418074033734		Wall fastening lug (4 pcs), for enclosures: • incl. screws
TH A	9802001	6418074034120		Grey plastic hinges (2 pcs) • incl. mounting screws
