מפה הנדסת חשמל בע"מ

מק"ט: PC/ABS 1224

מסמכים

Order symbol	Product nbr	EAN	Dimensions (mm)	Description • Remarks
PC 122410	7032780	6418074058430	244 x 124 x 102	Enclosure, PC • Grey cover
PCT 122410	7022781	6418074058645	244 x 124 x 102	Enclosure, PC • Transparent cover
PCQ 122410	7033781	6418074058997	244 x 124 x 102	Enclosure, PC • Grey cover (quick-locking)
PCTQ 122410	7022780	6418074059079	244 x 124 x 102	Enclosure, PC • Transparent cover (quick-locking)
AB 122410	7083780	6418074058850	244 x 124 x 102	Enclosure, ABS • Grey cover
ABQ 122410	7083781	6418074059154	244 x 124 x 102	Enclosure, ABS • Grey cover (quick-locking)
Accessories
TM 1224	9512016	6418074034052	214 x 111	Mounting plate, for enclosures:
TRM 0812	9820009	6418074034151	15 x 106	DIN-15 Mounting rail, for enclosures:
MIN 20	6314578	6418074023308	15 x 225	DIN-15 Mounting rail, for enclosures:
TRH 1212	9822002	6418074034403	35 x 110	DIN-35 Mounting rail, for enclosures:
TRH 24	9822008	6418074034397	35 x 226	DIN-35 Mounting rail, for enclosures:
TF 28037	7028337	6418074033734		Wall fastening lug (4 pcs), for enclosures: • incl. screws
TH A	9802001	6418074034120		Grey plastic hinges (2 pcs) • incl. mounting screws
