מק"ט: PC/ABS 2330

מסמכים

Order symbol	Product nbr	EAN	Dimensions (mm)	Description • Remarks
PC 233009	7032870	6418074003706	300 x 230 x 87	Enclosure, PC • Grey cover
PC 233011	7032890	6418074003713	300 x 230 x 110	Enclosure, PC • Grey cover
PCQ 233011	7033901	6418074012357	300 x 230 x 110	Enclosure, PC • Grey cover
PCT 233009	7022871	6418074003829	300 x 230 x 87	Enclosure, PC • Transparent cover
PCT 233011	7022891	6418074003836	300 x 230 x 110	Enclosure, PC • Transparent cover
PCTQ 233011	7022900	6418074012340	300 x 230 x 110	Enclosure, PC • Transparent cover
AB 233009	7083870	6418074003584	300 x 230 x 87	Enclosure, ABS • Grey cover
AB 233011	7083890	6418074003591	300 x 230 x 110	Enclosure, ABS • Grey cover
ABQ 233011	7083901	6418074012333	300 x 230 x 110	Enclosure, ABS • Grey cover
Accessories
TM 2330	9512019	6418074034083	221 x 274	Mounting plate, for enclosures:
TRM 0816	9820013	6418074034168	15 x 146	DIN-15 Mounting rail, for enclosures:
TRH 1216	9822028	6418074034410	35 x 146	DIN-35 Mounting rail, for enclosures:
TRH 2330	9822013	6418074034434	35 x 285	DIN-35 Mounting rail, for enclosures:
TF 28037	7028337	6418074033734		Wall fastening lug (4 pcs), for enclosures: • incl. screws
TH A	9802001	6418074034120		Grey plastic hinges (2 pcs) • incl. mounting screws
