Order symbol

Product nbr

EAN

Dimensions (mm)

Description • Remarks

ARCA 304015

8120022

6418074079336



300 x 400 x 150



Cabinet, PC • Grey cover, 2-point locking, hinges on the short side

ARCA 304021

8120023

6418074079343



300 x 400 x 210



Cabinet, PC • Grey cover, 2-point locking, hinges on the short side

ARCA 304015W

8120142

6418074080134



300 x 400 x 150



Cabinet, PC • Grey cover with window, 2-point locking, hinges on the short side

ARCA 304021W

8120143

6418074080141



300 x 400 x 210



Cabinet, PC • Grey cover with window, 2-point locking, hinges on the short side

ARCA 304015F

8120262

6418074080912



300 x 400 x 150



Cabinet, PC, flange • Grey cover, 2-point locking, hinges on the short side, flange opening size 2

ARCA 304021F

8120263

6418074080929



300 x 400 x 210



Cabinet, PC, flange • Grey cover, 2-point locking, hinges on the short side, flange opening size 2

ARCA 304015WF

8120382

6418074081698



300 x 400 x 150



Cabinet, PC, flange • Grey cover with window, 2-point locking, hinges on the short side, flange opening size 2

ARCA 304021WF

8120383

6418074081704



300 x 400 x 210



Cabinet, PC, flange • Grey cover with window, 2-point locking, hinges on the short side, flange opening size 2

Accessories

MPS ARCA 4030

8120733

6418074082565



350 x 250



Mounting plate • Galvanized steel, for sizes 400x300x150/210

MPP ARCA 4030

8120753

6418074082749



350 x 250



Mounting plate perforated • Galvanized steel, for sizes 400x300x150/210

MPX ARCA 4030

8120743

6418074082657



350 x 250



Mounting plate • Pertinax, for sizes 400x300x150/210

DRS ARCA 304015

8120793

6418074083012





DIN rail frame set • 1 row x 16 modules, for size 300x400x150

DRS ARCA 304021

8120794

6418074083029





DIN rail frame set • 1 row x 16 modules, for size 300x400x210

IDS ARCA 3040

8120911

6418074090195





Inner door set • Galvanized steel, for sizes 300x400x150/210

PMK ARCA 40

8120842

6418074083227





Pole mounting kit • For sizes 300x400x150/210, 500x400x210, 600x400x210
