Order symbol

Product nbr

EAN

Dimensions (mm)

Description • Remarks

ARCA 405021

8120025

6418074079367

400 x 500 x 210

Cabinet, PC • Grey cover, 2-point locking, hinges on the short side

ARCA 405021S

8120105

6418074079886

400 x 500 x 210

Cabinet, PC • Grey cover, swinghandle, hinges on the short side

ARCA 405021W

8120145

6418074080165



400 x 500 x 210



Cabinet, PC • Grey cover with window, 2-point locking, hinges on the short side

ARCA 405021SW

8120225

6418074080684



400 x 500 x 210



Cabinet, PC • Grey cover with window, swinghandle, hinges on the short side

ARCA 405021F

8120265

6418074080943



400 x 500 x 210



Cabinet, PC, flange • Grey cover, 2-point locking, hinges on the short side, flange opening size 1

ARCA 405021SF

8120345

6418074081469



400 x 500 x 210



Cabinet, PC, flange • Grey cover, swinghandle, hinges on the short side, flange opening size 1

ARCA 405021WF

8120385

6418074081728



400 x 500 x 210



Cabinet, PC, flange • Grey cover with window, 2-point locking, hinges on the short side, flange opening size 1

ARCA 405021SWF

8120465

6418074082244



400 x 500 x 210



Cabinet, PC, flange • Grey cover with window, swinghandle, hinges on the short side, flange opening size 1

Accessories

MPS ARCA 5040

8120735

6418074082589



450 x 350



Mounting plate • Galvanized steel, for size 500x400x210

MPP ARCA 5040

8120755

6418074082763



450 x 350



Mounting plate perforated • Galvanized steel, for size 500x400x210

MPX ARCA 5040

8120745

6418074082671



450 x 350



Mounting plate • Pertinax, for size 500x400x210

DRS ARCA 405021

8120796

6418074083043





DIN rail frame set • 2 rows x 22 modules, for size 400x500x210

IDS ARCA 4050

8120912

6418074090201





Inner door set • Galvanized steel, for size 400x500x210

PMK ARCA 50

8120843

6418074083234





Pole mounting kit • For sizes 400x500x210, 700x500x300
