Order symbol

Product nbr

EAN

Dimensions (mm)

Description • Remarks

ARCA 406021

8120026

6418074079374



400 x 600 x 210



Cabinet, PC • Grey cover, 2-point locking, hinges on the short side

ARCA 406021S

8120106

6418074079893



400 x 600 x 210



Cabinet, PC • Grey cover, swinghandle, hinges on the short side

ARCA 406021W

8120146

6418074080172



400 x 600 x 210



Cabinet, PC • Grey cover with window, 2-point locking, hinges on the short side

ARCA 406021SW

8120226

6418074080691



400 x 600 x 210



Cabinet, PC • Grey cover with window, swinghandle, hinges on the short side

ARCA 406021F

8120266

6418074080950



400 x 600 x 210



Cabinet, PC, flange • Grey cover, 2-point locking, hinges on the short side, flange opening size 2

ARCA 406021SF

8120346

6418074081476



400 x 600 x 210



Cabinet, PC, flange • Grey cover, swinghandle, hinges on the short side, flange opening size 2

ARCA 406021WF

8120386

6418074081735



400 x 600 x 210



Cabinet, PC, flange • Grey cover with window, 2-point locking, hinges on the short side, flange opening size 2

ARCA 406021SWF

8120466

6418074082251



400 x 600 x 210



Cabinet, PC, flange • Grey cover with window, swinghandle, hinges on the short side, flange opening size 2

Accessories

MPS ARCA 6040

8120736

6418074082596



550 x 350



Mounting plate • Galvanized steel, for size 600x400x210

MPP ARCA 6040

8120756

6418074082770



550 x 350



Mounting plate perforated • Galvanized steel, for size 600x400x210

MPX ARCA 6040

8120746

6418074082688



550 x 350



Mounting plate • Pertinax, for size 600x400x210

DRS ARCA 406021

8120797

6418074083050





DIN rail frame set • 2 rows x 27 modules, for size 400x600x210

IDS ARCA 4060

8120913

6418074090218





Inner door set • Galvanized steel, for size 400x600x210

PMK ARCA 60

8120844

6418074083241





Pole mounting kit • For sizes 400x600x210, 800x600x300
