Order symbol
|
Product nbr
|
EAN
|
Dimensions (mm)
|
Description • Remarks
|
|
ARCA 403015
|
8120006
|
6418074079176
|
400 x 300 x 150
|
Cabinet, PC • Grey cover, 2-point locking, hinges on the long side
|
|
ARCA 403015S
|
8120086
|
6418074079695
|
400 x 300 x 150
|
Cabinet, PC • Grey cover, swinghandle, hinges on the long side
|
|
ARCA 403015W
|
8120126
|
6418074079954
|
400 x 300 x 150
|
Cabinet, PC • Grey cover with window, 2-point locking, hinges on the long side
|
|
ARCA 403015SW
|
8120206
|
6418074080493
|
400 x 300 x 150
|
Cabinet, PC • Grey cover with window, swinghandle, hinges on the long side
|
|
ARCA 403015F
|
8120246
|
6418074080752
|
400 x 300 x 150
|
Cabinet, PC, flange • Grey cover, 2-point locking, hinges on the long side, flange opening size 2
|
|
ARCA 403015SF
|
8120326
|
6418074081278
|
400 x 300 x 150
|
Cabinet, PC, flange • Grey cover, swinghandle, hinges on the long side, flange opening size 2
|
|
ARCA 403015WF
|
8120366
|
6418074081537
|
400 x 300 x 150
|
Cabinet, PC, flange • Grey cover with window, 2-point locking, hinges on the long side, flange opening size 2
|
|
ARCA 403015SWF
|
8120446
|
6418074082053
|
400 x 300 x 150
|
Cabinet, PC, flange • Grey cover with window, swinghandle, hinges on the long side, flange opening size 2
|
|
ARCA 403021
|
8120007
|
6418074079183
|
400 x 300 x 210
|
Cabinet, PC • Grey cover, 2-point locking, hinges on the long side
|
|
ARCA 403021S
|
8120087
|
6418074079701
|
400 x 300 x 210
|
Cabinet, PC • Grey cover, swinghandle, hinges on the long side
|
|
ARCA 403021W
|
8120127
|
6418074079961
|
400 x 300 x 210
|
Cabinet, PC • Grey cover with window, 2-point locking, hinges on the long side
|
|
ARCA 403021SW
|
8120207
|
6418074080509
|
400 x 300 x 210
|
Cabinet, PC • Grey cover with window, swinghandle, hinges on the long side
|
|
ARCA 403021F
|
8120247
|
6418074080769
|
400 x 300 x 210
|
Cabinet, PC, flange • Grey cover, 2-point locking, hinges on the long side, flange opening size 2
|
|
ARCA 403021SF
|
8120327
|
6418074081285
|
400 x 300 x 210
|
Cabinet, PC, flange • Grey cover, swinghandle, hinges on the long side, flange opening size 2
|
|
ARCA 403021WF
|
8120367
|
6418074081544
|
400 x 300 x 210
|
Cabinet, PC, flange • Grey cover with window, 2-point locking, hinges on the long side, flange opening size 2
|
|
ARCA 403021SWF
|
8120447
|
6418074082060
|
400 x 300 x 210
|
Cabinet, PC, flange • Grey cover with window, swinghandle, hinges on the long side, flange opening size 2
|
|
Accessories
|
|
MPS ARCA 4030
|
8120733
|
6418074082565
|
350 x 250
|
Mounting plate • Galvanized steel, for sizes 400x300x150/210
|
|
MPP ARCA 4030
|
8120753
|
6418074082749
|
350 x 250
|
Mounting plate perforated • Galvanized steel, for sizes 400x300x150/210
|
|
MPX ARCA 4030
|
8120743
|
6418074082657
|
350 x 250
|
Mounting plate • Pertinax, for sizes 400x300x150/210
|
|
DRS ARCA 403015
|
8120764
|
6418074082855
|
|
DIN rail frame set • 2 rows x 11 modules, for size 400x300x150
|
|
DRS ARCA 403021
|
8120765
|
6418074082862
|
|
DIN rail frame set • 2 rows x 11 modules, for size 400x300x210
|
|
IDS ARCA 4030
|
8120713
|
6418074082381
|
|
Inner door set • Galvanized steel, for sizes 400x300x150/210
|
|
PMK ARCA 30
|
8120841
|
6418074083210
|
|
Pole mounting kit • For sizes 200x300x150, 400x300x150/210
|
