Order symbol

Product nbr

EAN

Dimensions (mm)

Description • Remarks

ARCA 608030

8120029

6418074085160



600 x 800 x 300



Cabinet, PC • Grey cover, 2-point locking, hinges on the short side

ARCA 608030S

8120109

6418074085221



600 x 800 x 300



Cabinet, PC • Grey cover, swinghandle, hinges on the short side

ARCA 608030W

8120149

6418074085245



600 x 800 x 300



Cabinet, PC • Grey cover with window, 2-point locking, hinges on the short side

ARCA 608030SW

8120229

6418074085283



600 x 800 x 300



Cabinet, PC • Grey cover with window, swinghandle, hinges on the short side

ARCA 608030SWF

8120469

6418074085405



600 x 800 x 300



Cabinet, PC, flange • Grey cover with window, swinghandle, hinges on the short side, flange opening size 3

ARCA 608030WF

8120389

6418074085368



600 x 800 x 300



Cabinet, PC, flange • Grey cover with window, 2-point locking, hinges on the short side, flange opening size 3

ARCA 608030SF

8120349

6418074085344



600 x 800 x 300



Cabinet, PC, flange • Grey cover, swinghandle, hinges on the short side, flange opening size 3

ARCA 608030F

8120269

6418074085306



600 x 800 x 300



Cabinet, PC, flange • Grey cover, 2-point locking, hinges on the short side, flange opening size 3

Accessories

MPP ARCA 8060

8120759

6418074082800



750 x 550



Mounting plate perforated • Galvanized steel, for size 800x600x300

MPS ARCA 8060

8120739

6418074082626



750 x 550



Mounting plate • Galvanized steel, for size 800x600x300

MPX ARCA 8060

8120749

6418074082718



750 x 550



Mounting plate • Pertinax, for size 800x600x300

DRS ARCA 608030

8120800

6418074085429





DIN rail frame set • 3 rows x 37 modules, for size 600x800x300

IDS ARCA 6080

8120915

6418074090232





Inner door set • Galvanized steel, for size 600x800x300

PMK ARCA 80

8120846

6418074083265





Pole mounting kit • For size 600x800x300
